Zilla Z1K-HV High Voltage 1000 Amps (72-300V nominal)
|
|
Motor, AC Motor & Controller Assembly, 50 hp,96 volt
|
|
Our Price: $2,675.00
|
|
|
|
Our Price: $4,295.00
|
|
|
|
|
|
The Z1K-HV controller can regulate up to 1000 Amps of motor current and run on battery packs of 72 to 300 volts nominal (375 volts maximum).
|
The system includes:
One HPGC AC50-01 Motor, 50 hp Peak, 15 hp continuous, 6500 RPM
One Curtis 550 amp Regen Controller number 1238-7501
Complete wiring harness interface
One Curtis 840 gauge, Indicates Motor RPM, Motor Temp, Controller Temp, plus a five
LED display that indicates efficiency, 2 green lights for best, 1 green light for less, 1 yellow, & 1 red for poorest. It indicates 3 green lights during regen. The display also contains diagnostics for the system
Also includes the Key Switch Relay
Requires a 24 volt main contactor not supplied, item SL3559. This contactor is driven by the controller
Uses any 0 to 5 k/ohm or 0 to 5 volt throttle input.
|
|
|
|
WarP 11 High Voltage
|
|
Zilla Z1K-LV Low Voltage 1000 Amps (72-156V nominal)
|
|
Our Price: $3,500.00
|
|
|
|
Our Price: $1,975.00
|
|
|
|
|
|
This motor looks and is the same size as the WarP 11 motor but is completely different internally! Designed for higher voltages, the motor can handle up to 336 Volts (in advanced timing*) and delivers up to 9000 RPM.
|
The Z1K-LV controller can regulate up to 1000 Amps of motor current and run on battery packs of 72 to 156 volts nominal (208 volts maximum). This unit is more than twice as powerful as the common 1231C type from the competition and therefore is plenty of power for most "normal" car conversions.
|
|
|
|
Elithion Distributed BMS
|
|
Thunder Sky - LiFeYPO4 - TS-LFP100AHA
|
|
|
|
Our Price: $110.00
|
|
|
|
|
|
Elithion BMS System for LiFePO4 batteries We offer a 2 year warranty on our batteries if you purchase this BMS This is the best BMS system currently available
Please contact us for a Price Quote since every system is unique
|
Nominal Capacity ：100AH
Operating Voltage：2.5V～4.25V
weight：3.2kg}100g
Dimensions：145~220~68（mm）
|
|
|
|
|
|
